Asus BE6800 Dual Band RT-BE86U Performance Wifi 7 Extendable Router 2.6Hz Quad-Core CPU For Ultra-Fast Network Speed

Model No : Asus BE6800 Dual Band RT-BE86U Performance Wifi 7 Extendable Router Part No : 90IG08W0-MO9A0V Network Standard : IPv6IPv4WiFi 7 (802.11be)WiFi 6 (802.11ax)WiFi 5 (802.11ac)WiFi 4 (802.11n)IEEE 802.11gIEEE 802.11bIEEE 802.11a Product Segment : BE6800 ultimate BE performance : 1032+5764 Mbps WiFi Data Rate : WiFi 7 (802.11be) (5GHz): up to 5764 MbpsWiFi 7 (802.11be) (2.4GHz): up to 1032 Mbps Antenna : External antenna x 3； Internal antenna x 1 Transmit/Receive : 5GHz 4x42.4GHz 3x3 Processor : 2.6GHz quad-core processor Memory : 256 MB Flash and 1 GB RAM Boosts speed : OFDMA (Orthogonal Frequency Division Multiple Access)Beamforming: standard-based and universal4096-QAM high data rate20/40/80/160 MHz bandwidth Operating Frequency : 5 GHz2.4 GHz Operating Mode : Repeater ModeMedia Bridge ModeAccess Point ModeAiMesh Node ModeWireless Router Mode Ports : 1 x 10G for WAN/LAN, 1 x 2.5G for WAN/LAN, 3 x 2.5G for LAN, USB 3.2 Gen1 x1, USB 2.0 Gen1 x1 Button : WPS Button, Reset Button, Power Button, Wireless on/off Button, LED on/off Button LED Indicator : WAN x110G Port x1LAN x4USB x12.4GHz x15GHz x1Power x1 Power Supply : AC Input : 110V~240V(50~60Hz)DC Output : 12 V with max. 5 A current ； 19.5 V with max. 2.31 A current AiMesh : • AiMesh Node• Primary AiMesh RouterAiMesh Game : Gaming PortOpenNAT (Game Profile)Gear AcceleratorMobile Game Mode Parental Control : Web & Apps FiltersTime SchedulingSafe BrowsingCustomized Internet Schedule"Allow you to block access to unwanted websites and apps."• Maximum Parental Control Profile : 64• Maximum Parental Control Content Cilter Rule : 64 Guest Network : Support Guest Network Pro"You can create additional networks for different purposes, these networks are separate from the main network domain, to provide enhanced security, and create comprehensive network environment with customized settings."Guest Network Connection Time Limit• Maximum Guest Network Rule : 2.4 GHz + 5 GHz : 5Guest Network Pro Encryption : Open system, WPA/WPA2-Personal/WPA3-Personal AiProtection : AiProtection Pro• Infected Device Prevention and Blocking• Two-Way IPS• Malicious Site Blocking• Router Security Assessment Security : VPNDNS-over-TLSSecurity ScanSSHFirewallLet's EncryptWPSAiProtectionWPA3 Personal, WPA2 Personal, WPA Personal, WPA Enterprise, WPA2 Enterprise, WPA3 Enterprise, Open System & OWE• Maximum Firewall Keyword Filter : 64• Maximum Firewall Network Service Filter : 32• Maximum Firewall URL Filter : 64 Wireless : MU-MIMORADIUS ClientExplicit BeamformingUniversal BeamformingAirtime FairnessWireless SchedulerWiFi MAC Address FilterUTF-8 SSID• Maximum MAC Filters : 64 WAN : • PPPoE Relay• IPSec• SIP Pass-Through• H.323 Pass-Through• Static IP• RTSP Pass-Through• Automatic IP• IPSec Pass-Through• L2TP• L2TP Pass-Through• PPTP• PPTP Pass-Through• PPPoENAT Passthrough :Internet Connection Type :DDNSDMZPort triggeringPort forwarding3G / 4G LTE dongleWAN AggregationDual WAN• Maximum Port Forwarding Rule : 64• Maximum Port Triggering Rule : 32 LAN : Manually Assign IP AddressWake on LAN (WOL)LAN Link AggregationIPTVIGMP SnoopingDHCP Server• Maximum Manually Assign IP Address Rule : 128 VPN : Support SurfsharkInstant GuardVPN Client WireGuardVPN Server WireGuardVPN FusionVPN Server PPTPVPN Server Open VPNVPN Server IPSecVPN Client PPTPVPN Client Open VPNVPN Client L2TP USB application : • ext4• ext3• ext2• vFAT• NTFS• HFS+File System :Samba ServerShared Folder PrivilegesFTP ServerTime MachineMedia ServerAiDiskDownload MasterAiCloudSafely Remove Disk Administration : New Device Connect NotificationLogin CaptchaConnection DiagnosisAuto Firmware UpdateConfiguration Backup and RestoreDiagnosis toolsFeedback SystemSystem Log Dimension : 235*90*316 mm Weight : 854 g Package content : RT-BE86U WiFi routerRJ-45 cablePower adapterQuick Start GuideWarranty card Warranty : 1 Year ( As per Manufacturer Policy )
