Asus Intel ROG Maximus Xll Hero (Wi-Fi) Gaming MotherBoard

Model No : ROG Maximus Xll Hero (Wi-Fi) Part No : 90MB12R0-M0EAY0 CPU : Intel® Socket 1200 for 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors : Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0** : **Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types. : Supports Intel® 14nm CPU Chipset : Intel® Z490 Memory : 4 x DIMM, Max. 128GB, DDR4 4800(O.C.)/4700(O.C)/4600(O.C)/4500(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3200(O.C.)/3000(O.C.)/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory * : OptiMem III : * 10th Gen Intel® Core™i9/i7 CPUs support 2933/2800/2666/2400/2133 natively, Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). : Dual Channel Memory Architecture : Supports Intel® Extreme Memory Profile (XMP) Graphic : 1 x HDMI 1.4b : *Graphics specifications may vary between CPU types. : Integrated Graphics Processor Multi-GPU Support : Supports NVIDIA® 2-Way SLI® Technology : Supports AMD 3-Way CrossFireX™ Technology : Supports AMD 2-Way CrossFireX Technology Expansion Slots : 2 x PCIe 3.0 x16 (x16 or dual x8) *1 : 1 x PCIe 3.0 x16 (x4 mode) *2 : Intel® 10th Gen Processors : Intel® Z490 Chipset : 3 x PCIe 3.0 x1 Storage : Total supports 3 x M.2 slots and 6 x SATA 6Gb/s ports : 1 x M.2_1 socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)*3 : 1 x M.2_2 socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)*4 : 1 x M.2_3 socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode) : Intel® Z490 Chipset : : 6 x SATA 6Gb/s port(s), : Support Raid 0, 1, 5, 10 : Intel® Optane™ Memory Ready LAN : Intel® I219-V 1Gb Ethernet : Marvell® AQtion AQC111C 5Gb Ethernet : ASUS LANGuard Wireless Data Network : Intel® Wi-Fi 6 AX201 : 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) support 1024QAM/OFDMA/MU-MIMO : Supports up to 2.4Gbps max data rate : Supports CNVI interface : Supports dual band frequency 2.4/5 GHz : Supports channel bandwidth: HT20/HT40/HT80/HT160 Bluetooth : Bluetooth v5.1* : *BT 5.1 function will be ready in Windows 10 build 19041 or later. Audio : ROG SupremeFX7.1 Surround Sound High Definition Audio CODEC S1220*6 : - Supports : Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback : - ESS™ ES9023 DAC + RC4580 OP AMP : - Premium Japanese audio capacitors : - Audio Cover : - Impedance sense for front and rear headphone outputs : - High quality120dBSNR stereo playback outputand113dBSNR recording input : - Supports up to 32-Bit/192kHz playback : Audio Feature : : - SupremeFX Shielding™ Technology : - Gold-plated jacks : - Optical S/PDIF out port(s) at back panel USB Ports : 4 x USB 3.2 Gen 2 port(s)(3 + Type-A +1 + USB Type-C®) : 4 x USB 3.2 Gen 1 port(s)(4 x Type-A) : Front USB Port ( Total 7 ) : Rear USB Port ( Total 10 ) : 2 x USB 2.0 port(s)(2 x Type-A) : 2 x USB 3.2 Gen 1 port(s) : 1 x USB 3.2 Gen 2 front panel connector port(s) : 4 x USB 2.0 port(s) Software Features : [ROG Exclusive Software] : - Mem Tweakit : - RAMCache III : - ROG CPU-Z : - GameFirst VI : - Sonic Studio III + Sonic Studio Virtual Mixer : - Sonic Radar III : - DTS® Sound Unbound : - Overwolf : - BullGuard Internet Security (1-year full version) : [ASUS Exclusive Software] : Armoury Crate : - Aura Creator : - Aura Sync : AI Suite 3 : - 5-way Optimization with AI Overclocking: TPU, EPU, Digi+ Power Control, Fan Xpert 4, Turbo app : - EZ update : AI Charger : WinRAR : [UEFI BIOS] : AI Overclocking Guide : ASUS EZ DIY : - ASUS CrashFree BIOS 3 : - ASUS EZ Flash 3 : - ASUS UEFI BIOS EZ Mode : FlexKey ASUS Special Features : ROG Extreme OC kit : - FlexKey button : - ReTry button : - Start button : Extreme Engine Digi+ : - 10K Black Metallic Capacitors : - MicroFine Alloy Choke : ASUS Q-Design : - ASUS Q-Code : - ASUS Q-Connector : - ASUS Q-DIMM : - ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) : - ASUS Q-Slot : ASUS Thermal Solution : - Aluminum M.2 heatsink cover : ASUS EZ DIY : - BIOS Flashback™ button : - Clear CMOS button : - Procool II : - Pre-mounted I/O shield : - SafeSlot : AURA Sync : - Standard RGB headers : - Addressable Gen 2 RGB headers Back I/O Ports : 1 x Marvell® AQtion AQC111C 5Gb Ethernet : 1 x Intel® I219-V 1Gb Ethernet : 1 x USB BIOS FlashBack™ Button(s) : 4 x USB 3.2 Gen 2 : 4 x USB 3.2 Gen 1 : 1 x HDMI : 2 x USB 2.0 : 1 x Optical S/PDIF out : 1 x Clear CMOS button(s) : 1 x ASUS Wi-Fi Module : 5 x Gold-plated audio jacks Internal I/O Ports : 3 x M.2 Socket 3 : 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) : 1 x USB 3.2 Gen 2 front panel connector : 1 x FlexKey button : 1 x Thunderbolt header(s) : 1 x CPU Fan connector(s) : 1 x CPU OPT Fan connector(s) : 3 x Chassis Fan connector(s) : 1 x AIO_PUMP connector : 1 x H_AMP fan connector : 1 x W_PUMP+ connector : 1 x W_IN header : 1 x W_OUT header : 1 x W_FLOW header : 1 x AAFP connector : 2 x Aura RGB Strip Headers : 2 x Addressable Gen 2 header(s) : 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) : 6 x SATA 6Gb/s connector(s) : 1 x 24-pin EATX Power connector(s) : 1 x 8-pin ATX 12V Power connector(s) : 1 x 4-pin ATX 12V Power connector(s) : 1 x Thermal sensor connector(s) : 1 x ReTry button : 1 x System panel connector : 1 x Speaker connector : 1 x Start button Accessories : 2 x M.2 SSD screw package(s) : 2 x M.2 Rubber Package(s) : 1 ROG key chain : Addressable LED extension cable : 1 x MOS Cooling kit (fan bracket and 40mm x 40mm fan) : User´s manual : 1 x ROG logo plate sticker : 4 x SATA 6Gb/s cable(s) : 1 x Supporting DVD : 1 x ROG big sticker : 1 x Q-Connector : 1 x Wi-Fi Antenna(s) : 1 x Extension Cable for RGB strips (80 cm) : 1 x ROG Thank you card BIOS : 256 Mb Flash ROM, UEFI AMI BIOS Manageability : WOL by PME, PXE Operating System : Windows® 10 64-bit Form Factor : 12 inch x 9.5 inch ( 30.5 cm x 24.4 cm ) : ATX Form Factor
