Asus RT-AX86U Pro Performance Wifi 6 Gaming Router Ai Mesh 2.5 Gbps Port

Key Specifications

• Model NoAsus RT-AX86U Pro Performance Wifi 6 Gaming Router
• Part No90IG07N0-MU2B00Network StandardIEEE 802.11aIEEE 802.11bIEEE 802.11gWiFi 4 (802.11n)WiFi 5 (802.11ac)WiFi 6 (802.11ax)IPv4IPv6SegmentAX5700 ultimate AX performance: 861+4804 MbpsData Rate802.11a: up to 54 Mbps802.11b: up to 11 Mbps802.11g: up to 54 MbpsWiFi 4 (802.11n): up to 450 MbpsWiFi 4 (802.11n) (1024QAM): up to 750 MbpsWiFi 5 (802.11ac) (1024QAM): up to 4333 MbpsWiFi 6 (802.11ax) (2.4GHz): up to 861 MbpsWiFi 6 (802.11ax) (5GHz): up to 4804 MbpsAntennaExternal antenna x 3Internal PCB antenna x 1Transmit/Receive2.4GHz 3x35GHz 4x4
• Processor2.0GHz quad-core processor
• Memory256 MB Flash and 1 GB RAMBoosts speedOFDMA (Orthogonal
• Frequency Division Multiple Access)Beamforming: standard-based and universal1024-QAM high data rate20/40/80/160 MHz bandwidthOperating
• Frequency2.4 GHz / 5 GHzOperating ModeWireless router mode,Access point mode,Media bridge mode,Repeater mode,AiMesh node modePortsRJ45 for 10/100/1000 BaseT for WAN x 1RJ45 for 10/100/1000 BaseT for LAN x 4Five (5) 10/100/1000 Mbps Gigabit Ethernet ports + one (1)2.5G/1Gbps multi-Gig port (configurable)-- LAN: 4xGbE (2x port aggregation LAN)-- WAN: 1 GbE-- WAN/LAN: 2.5G/1Gbps multi-Gig port (configurable)-- Multi-Gig: Ability to aggregate two Gigabit LAN ports and two Gigabit WAN ports (configurable) concurrently.USB 3.2 Gen1 x1, 2.0 x1ButtonWPS Button, Reset Button,
• Power Switch, LED on/off ButtonLED Indicator
• Power x 12.4GHz x 15GHz x 12.5G Port x 1WAN x 1LAN x 4WPS x 1
• Power Supply19 V with max. 2.37 A current / 19.5 V with max. 2.31 A current or12 V with max.3 A current / 19.5 V with max. 2.31 A currentAiMeshAiMesh• Primary AiMesh Router• AiMesh NodeGameGame Boost / AccelerationMobile Game ModeGear AcceleratorParental Control"Allow you to block access to unwanted websites and apps."Safe BrowsingCustomized Internet Schedule• Maximum Parental Control Profile: 64• Maximum Parental Control Content Cilter Rule: 64Guest Network"The Guest Network provides Internet connection for guests but restricts access to your local network."• Maximum Guest Network Rule: 2.4GHz x3, 5GHz x3Guest Network Connection Time LimitGuest Network Encryption: Open system, WPA/WPA2/WPA3-Personal, WPSAiProtectionRouter Security Assessment• Malicious Site Blocking• Two-Way IPS• Infected Device Prevention and BlockingSecurityAiProtectionWPA3-Personal, WPA2-Personal, WPA-Personal, WPA-Enterprise, WPA2-Enterprise, WPS supportWPSLet's EncryptDNS-over-TLSSSHSecurity ScanFirewall• Maximum Firewall Keyword Filter: 64• Maximum Firewall Network Service Filter: 32• Maximum Firewall URL Filter: 64WirelessMU-MIMOUTF-8 SSIDWiFi MAC Address Filter• Maximum MAC Filters: 64Wireless SchedulerAirtime FairnessRADIUS ClientUniversal BeamformingExplicit BeamformingWANInternet connection Type: PPPoE, PPTP, L2TP, Automatic IP, Static IPDual WANWAN Aggregation3G / 4G LTE donglePort forwarding• Maximum Port Forwarding Rule: 64Port triggering• Maximum Port Triggering Rule: 32DMZDDNSNAT Passthrough: PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, PPPoE relayLANDHCP ServerIGMP SnoopingIPTVLAN Link AggregationManually Assign IP Address• Maximum Manually Assign IP Address Rule: 64Wake on LAN (WOL)VPNInstant GuardVPN Client L2TPVPN Client Open VPNVPN Client PPTPVPN Client WireGuardVPN Server IPSecVPN Server Open VPNVPN Server PPTPVPN Server WireGuardVPN FusionWirelessMU-MIMOUTF-8 SSIDWiFi MAC Address Filter• Maximum MAC Filters: 64Wireless SchedulerAirtime FairnessRADIUS ClientUniversal BeamformingExplicit BeamformingUSB applicationFile System: HFS+, NTFS, vFAT, ext2, ext3, ext4Safely Remove DiskAiCloudDownload MasterAiDiskMedia ServerTime MachineSamba ServerFTP ServerShared Folder PrivilegesAdministrationConfiguration Backup and RestoreDiagnosis toolsFeedback SystemSystem LogNew Device Connect NotificationLogin CaptchaConnection DiagnosisAuto Firmware UpdateDimension242 x 100 x 325 (with antenna)242 x 100 x 164 (without antenna)Weight814.5 gPackage contentRT-AX86U Pro WiFi routerRJ-45 cable
• Power adapterQuick Start Guide
• Warranty card
• Warranty1 Year ( As per Manufacturer Policy )
