GigaByte AMD TRX40 DESIGNARE DDR4 Gaming Motherboard

Engineered for Extreme Content Creation

The GIGABYTE TRX40 DESIGNARE is a workstation-class motherboard designed to unleash the full potential of 3rd Gen AMD Ryzen Threadripper processors. Built specifically for creators, designers, and power users, it provides the massive bandwidth required for heavy multi-threaded tasks such as 8K video rendering, 3D simulation, and complex data processing. With its professional aesthetic and industrial-grade reliability, the DESIGNARE series represents the perfect balance of raw power and sophisticated design.

Unrivaled Memory and PCIe Gen4 Expansion

Equipped with Quad-Channel DDR4 support across eight DIMM slots, this motherboard allows for massive memory configurations to handle the most demanding projects. The TRX40 platform brings full PCIe 4.0 support, offering double the bandwidth of the previous generation. This allows for lightning-fast NVMe storage arrays and multi-GPU configurations without bottlenecks. The included GC-Titan Ridge add-in card further expands the board's capabilities, providing ultra-fast Thunderbolt 3 connectivity for professional peripherals and high-speed external storage.

Thermal Excellence and Premium Connectivity

To ensure stability under 24/7 heavy workloads, the TRX40 DESIGNARE features an advanced thermal solution, including a Fins-Array heatsink, heatpipe with an extended coating, and a dedicated baseplate. The board is packed with high-end connectivity, including Dual Intel Gigabit LAN and built-in Wi-Fi 6 (802.11ax) for seamless networking. With multiple M.2 slots and an included AORUS Gen4 AIC Adaptor, you can build a massive, high-speed storage ecosystem that keeps up with your creative workflow.

Key Specifications

• Socket: AMD Socket sTRX4 (Optimized for 3rd Gen Ryzen Threadripper).

• Chipset: AMD TRX40.

• Memory Support: 8 x DDR4 DIMM Slots (Quad-Channel, Supports ECC/Non-ECC).

• Expansion Slots: 4 x PCIe 4.0 x16 (Supports multi-GPU configurations).

• Storage Interface: 3 x M.2 PCIe 4.0 Slots on-board + 8 x SATA 6Gb/s.

• Networking: Dual Intel GbE LAN, Intel Wi-Fi 6 802.11ax, and Bluetooth 5.

• Thunderbolt: Included GC-Titan Ridge Card for dual Thunderbolt 3 support.

• Audio: ALC1220-VB 120dB SNR HD Audio with high-end WIMA Capacitors.

• USB Ports: USB 3.2 Gen2 Type-C and Type-A connectivity.

• Form Factor: XL-ATX.
