MSI MPG Z790 CARBON WIFI DDR5 ATX Motherboard

Model No : MSI MPG Z790 CARBON WIFI DDR5 ATX Motherboard Part No : 911-7D89-001 Chipset : INTEL Z790 Form Factor : ATX243.84mmx304.8mm Socket Compatibility : Supports 12th/13th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® ProcessorsLGA 1700 Wireless & Bluetooth : Intel® Wi-Fi 6EThe Wireless module is pre-installed in the M.2 (Key-E) slotSupports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4GbpsSupports 802.11 a/ b/ g/ n/ ac/ axSupports Bluetooth® 5.3, FIPS, FISMA* Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in Windows 10 build 21H1 and Windows 11." Graphics : 1x HDMI™Support HDMI™ 2.1 with HDR, maximum resolution of 4K 60Hz**Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. Memroy : 4x DDR5, Maximum Memory Capacity 192GBMemory Support 7600+(OC)/ 7400 (OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHzMax. overclocking frequency:• 1DPC 1R Max speed up to 7600+ MHz• 1DPC 2R Max speed up to 6600+ MHz• 2DPC 1R Max speed up to 6400+ MHz• 2DPC 2R Max speed up to 5600+ MHzSupports Intel® XMP3.0 OCSupports Dual-Controller Dual-Channel modeSupports non-ECC, un-buffered memory Storage Compatibility : 5x M.2M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devicesM.2_2 Source (From CPU) supports up to PCIe 5.0 x4 , supports 22110/2280/2260 devicesM.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devicesM.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devicesM.2_5 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260 devices6x SATA 6G*PCI_E1 slot will be Gen5x8 when installing M.2 SSD in the M2_2 slot. Back Panel I/O Ports : Clear CMOS / FlashUSB 3.2 Gen 1 5 Gbps (Type-A)2.5G LANUSB 3.2 Gen 2 10Gbps (Type-A)Audio ConnectorsSmart ButtonHDMI™USB 3.2 Gen 2 10Gbps (Type-A)USB 3.2 Gen 2 10Gbps (Type-C)USB 3.2 Gen 2x2 20Gbps (Type-C)Wi-Fi / BluetoothOptical S/PDIF Out USB Ports : 4x USB 2.0 (Front)2x USB 3.2 Gen1 Type A (Rear)2x USB 3.2 Gen1 Type A (Front)6x USB 3.2 Gen2 Type A (Rear)1x USB 3.2 Gen2 Type C (Rear)1x USB 3.2 Gen2x2 Type C (Rear)1x USB 3.2 Gen2x2 Type C (Front) Expansion Slots : 2x PCI-E x16 slot1x PCI-E x1 slotPCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) Audio : Realtek® ALC4080 Codec7.1-Channel USB High Performance AudioSupports up to 32-Bit/384 kHz playback on front panel Internal I/O Connectors : 1x Power Connector(ATX_PWR)2x Power Connector(CPU_PWR)1x CPU Fan1x Pump Fan5x System Fan2x Front Panel (JFP)1x Chassis Intrusion (JCI)1x Front Audio (JAUD)1x TBT connector (JTBT, supports RTD3)1x Tuning Controller connector(JDASH)2x Addressable V2 RGB LED connector (JARGB_V2)1x RGB LED connector(JRGB)1x TPM pin header(Support TPM 2.0)4x USB 2.0 ports2x USB 3.2 Gen1 Type A ports1x USB 3.2 Gen 2x2 Type C ports Special Features : ATX Form FactorIntel Z790 ChipsetLGA 1700 Socket4 x Dual-Channel DDR5-6666 (OC)6 x SATA III, 5 x M.21 x PCIe 5.0 x16 & 1 x PCIe 4.0 x16 Slot1 x PCIe 3.0 x1 Slot7.1-Channel Realtek ALC4080 Codec2.5 GbE LAN, Wi-Fi 6E & Bluetooth 5.2USB 3.2 Gen 2 & Gen 2x2 Type-C Ports Warranty : 1 Year ( As per Manufacturer Policy )
