MSI Pro B840-P Wifi, PCIe 4.0 Ready DDR5 AMD Ryzen Gaming MotherBoard

Model No : PRO B840-P WIFI Part No : 911-7E57-001 Chipset : AMD B840 Form Factor : ATX Socket Compatibility : Supports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop ProcessorsSocket AM5 Wireless & Bluetooth : Wi-Fi 7The Wireless module is pre-installed in the M.2 (Key-E) slotSupports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (320MHz) up to 5.8GbpsSupports 802.11 a/ b/ g/ n/ ac/ ax/ beSupports Bluetooth® 5.4**, MLO, 4KQAM Lighting : 4x EZ Debug LED Memroy Type : 4x DDR5 UDIMM, Maximum Memory Capacity 256GBMemory Support DDR5 8000 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/sRyzen™ 9000 Series Processors max. overclocking frequency:• 1DPC 1R Max speed up to 8000+ MT/s• 1DPC 2R Max speed up to 6400+ MT/s• 2DPC 1R Max speed up to 6400+ MT/s• 2DPC 2R Max speed up to 4800+ MT/s Memory Compatibility : Supports AMD POR Speed and JEDEC SpeedSupports Memory Overclocking and AMD EXPOTMSupports Dual-Channel modeSupports Non-ECC, Un-buffered memorySupports CUDIMM, Clock Driver bypass mode only LAN : Realtek® 8125D 2.5G LAN Storage Compatibility : 2x M.2M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devicesM.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260 devices4x SATA 6GM2_2 slot• Supports up to PCIe 4.0 x4 (For Ryzen™ 9000/ 7000 Series processors)• Supports up to PCIe 3.0 x4 (For Ryzen™ 8700/ 8600/ 8400 Series processors)• Supports up to PCIe 3.0 x2 (For Ryzen™ 8500/ 8300 Series processors) Back Panel I/O Ports : Clear CMOS ButtonUSB 10Gbps Type-AUSB 2.02.5G LANWi-Fi / BluetoothAudio connectorsFlash BIOS ButtonHDMI™USB 10Gbps Type-CUSB 5Gbps Type-A USB Ports Front (Support ) : 2x USB 5Gbps Type A 1x USB 5Gbps Type C Expansion Slots : 5x PCI-E x16 slotPCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset)PCI_E4 Gen PCIe 3.0 supports up to x4 (From Chipset)PCI_E5 Gen PCIe 3.0 supports up to x1 (From Chipset)PCI_E1 slot• Supports PCIe 4.0 x16 (For Ryzen™ 9000/ 7000 Series processors)• Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors)• Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processors) Audio : Realtek® ALC8977.1-Channel High Definition Audio Internal I/O Connectors : Power Connectors (ATX, CPU), 1x CPU Fan, 1x Pump/Combo Fan, 4x System Fans, TPM 2.0, RGB and Addressable RGB LED Headers Special Features : The motherboard also supports RAID 0, RAID 1, and RAID 10 configurations for SATA storage devices. The AI LAN Manager optimizes networking performance by prioritizing latency-sensitive applications, ensuring a seamless online experience. Package Content : European Union Ragulaloty Notice, Quick Installation Guide, EZ M.2 Clip II Remover, 2x EZ M.2 Clip II, EZ Wi-Fi Antina, Sata cable Product Size ( Dimension ) : 345 mm x 273 mm x 72 mm Product Weight : 2.0 Kg Warranty : 1 Year ( As per Manufacturer Policy )
