Silver Stone Essential Series AT750 80 Plus Bronze Certified 750W ATX Power Supply - Black

Model No : Silver Stone Essential Series AT750 80 Plus Bronze 750W ATX Power Supply Part No : SST-AT750R-BF Power : 750W Efficiency Standard : 82% ~ 85% (at 20% ~ 100% loading) (BRONZE) Modularity : Standard Color : Black PSU Form Factor : ATX Fan : Single Silent 120mm fan Protection Features : Over Power ProtectionOver Voltage ProtectionShort Circuit ProtectionUnder Voltage Protection Load Range : Output: +3.3V +5V +12V +5VSB -12VMax.(Amps): 20A 20A 62.5A 3A 0.3AMin.(Amps): 0A 0A 0A 0A 0ARange (%): ±5% ±5% +5~-7% ±5% ±10%Line Reg.(%): ±1% ±1% ±1% ±1% ±1%Ripple(mVp-p): 50mV 50mV 120mV 50mV 50mV Input Voltage : 90 ~ 264 Vrms Input Frequency Range : 47Hz ~ 63Hz PFC : Active PFC (PF>0.9 at full load) MTBF : 100,000 hours Special Features : Compliant with ATX 3.1 standards and supports up to 2X power excursionHigh efficiency with 80 PLUS Bronze certification24/7 continuous power output with 50℃ operating temperatureJapanese primary capacitorSilent running 120mm fan with 18 dBA minimumMultiple protection circuitryAll black flat cablesActive PFC+Double forward+DC to DC Design Connectors : 1 x 24 / 20-Pin motherboard connector2 x 4-Pin + 4-Pin ATX 12V connector4 x 8 / 6-Pin PCIe connector6 x SATA connectors3 x 4-Pin Peripheral connector Dimension : 150mm (W) × 86mm (H) × 140mm (D) Weight : 1.54 kg Warranty : 1 Year ( As per Manufacturer Policy )
