Silver Stone Essential Series ET750 80 Plus Gold Certified 750W ATX Power Supply - Black

Model No : Silver Stone Essential Series ET750 80 Plus Gold 750W Power Supply Part No : SST-ET750-G Power : 750W Efficiency Standard : 87% ~ 90% at 20% ~ 100% loading (GOLD) Modularity : Standard Color : Black PSU Form Factor : ATX Fan : Single 120mm silent fan Protection Features : Over current protectionOver power protectionOver voltage protectionShort circuit protectionOver temperature protection Load Range : Output : +3.3V, +5V, +12V, +5VSB, -12VMax.(Amps) : 20A, 20A, 70.5A, 2.5A, 0.3APeak (Amps) : / / / / 3.0AMin.(Amps) : 0A, 0A, 0A, 0A, 0ARange (%) : ±3%, ±3%, ±3%, ±3%, ±10%Line Reg.(%) : ±1%, ±1%, ±1%, ±1%, ±1%Ripple(mVp-p) : 40mV, 40mV, 60mV, 40mV, 80mV Input Voltage : 90 ~ 264 Vrms Input Frequency Range : 47Hz ~ 63Hz PFC : Active PFC（PF>0.9 at full load） MTBF : 100,000 hours Special Features : High efficiency with 80 PLUS Gold certification24/7 continuous power output with 40℃ operating temperatureClass-leading single +12V railSilent running 120mm fan with 18 dBAPCIe 8pin and PCIe 6pin connectors supportAll-black flat cables designDual EPS 8pin with multiple PCI-E 8 / 6pin connectors support (V1.2) Connectors : 1 x 24 / 20-Pin motherboard connector (500mm)1 x 8 / 4-Pin EPS / ATX 12V connector (750mm)4 x 8 / 6-Pin PCIe connector ("500mm / 150mm" x 2)8 x SATA connector ("500mm / 150mm / 150mm / 150mm" x 2)3 x 4-Pin Peripheral connector (500mm / 150mm / 150mm)1 x 4-Pin Floppy connector (500mm / 150mm / 150mm / 150mm) Dimension : 150 mm (W) x 86 mm (H) x 140 mm (D) Weight : 1.68 Kg Warranty : 1 Year ( As per Manufacturer Policy )
